Ideal para limpieza de maíz, frijol y garbanzo en plantas procesadoras
1 / 4

Gravity Table Grain Cleaner for Corn, Beans and Chickpeas

Model: 5XFZ-25SC

cribadora

Gravity Table Grain Cleaner for Corn, Beans and Chickpeas The gravity table grain cleaner is a combined air and density separation machine designed for grain cleaning. It integrates elevation, air separation, ecological dust cleaning, screening and density separation in a single operation. It is ideal for cleaning corn, beans and chickpeas in plants. It removes dust, husks, large and small impurities, as well as empty seeds, sprouted grains, insect-damaged grains, moldy grains and black disease-affected grains, ensuring the quality and appearance of the final product. Features - Efficient grain cleaning in one pass - Removes fine, coarse impurities and damaged grains - Gravity table for density classification - Robust equipment adaptable to different crops - Improves grain purity and appearance

Detailed Description

1. This multifunctional machine is suitable for processing various materials and can replace sorting equipment for materials that do not require high purity.

2. Two screening layers have been added before the gravity concentrator to remove large and small impurities after air sorting, thus reducing the workload of the gravity concentrator and improving its efficiency and output.

3. Air sorting, screening, and gravity sorting are performed in a single operation, reducing labor, saving space, and consuming less energy.

4. This machine is equipped with an environmental dust removal system, which can effectively collect dust and prevent contamination of the working environment.

5. Vibrating screens of different lengths are available.

Name

Model

Size

(mm)

Power

(kw)

Capacity

(t/h)

Weight

(kg)

Dimension

(mm)

Voltage

Cribadora con mesa gravedad

5XFZ-25S

1700*1600

13

10

2000

4000*2300*4000

380V50HZ

Cribadora con mesa gravedad

5XFZ-25SC

1700*1600

13

10

2000

4400*2300*4000

380V50HZ
